Trench Sheets – FLP 600/3.5 (S275 JRC)

Trench Sheets – FLP 600/3.5 (S275 JRC)

Trench sheets provide an effective ground solution to support the vertical faces of small to medium sized trenches and excavations.
  • Galvanising service
  • Clutch sealing service
Profile
FLP 600/3.5
Steel Grade
S275
Width (mm)
600
Height (mm)
128
Thickness (mm)
3.5
Weight (kg/m)
23.1
Weight (kg/m²)
38.5
Section Modulus Z (cm³/m)
183.0
Moment Capacity (kNm/m)
33.5

You must be logged in to download files.

Login

Register

No 3D Renders available.
